Ariel Nomad Sport Specifications
From $80,000 US
Once there was just the Atom. Lightweight, simple, fast, fun. A pure sports car distilled down to its basic function. Beautifully engineered, exquisitely built and designed for a purpose. Now that purpose just took a big left turn and went right off road. But you can see that the Ariel Nomad is an Ariel through and through. The same thought in design, the same attention to detail and the same Ariel grin on your face. Sharing that Atom thought process, the Atom philosophy and some proven Atom components the Nomad opens up a whole new dimension to having fun on four wheels. Where the Atom is to road and track, the Nomad is to road and off it. Whether it's a gravel track, a WRC rally stage, a green lane, a desert or just a grassy field the Ariel Nomad calls this home. And could this be the coolest car on the road? A modern buggy designed for the rough and tough of the wild but just as home in the city and just as much fun.
Is the Nomad Sport for you? Read on!
You love corners of every shape and condition. Tarmac on the road or track. Pot Holes be damned! The Ariel Nomad Sport is the perfect tool to get your pulse racing. Well equipped, rugged, light-weight, Honda-powered reliability and sport tuned to annihilate any road – regardless of condition!
The Nomad Sport is the rally racer to fulfill all your dreams!
2.4 K24 Honda 4 cylinder i-VTEC. Alloy block, cylinder head, sump
Displacement 2354cc. Bore & Stroke 87mm x 99mm.
Chain drive DOHC 4 valves per cylinder
230 HP @ 7200 rpmTorque 220 ft/lbs @ 4300 rpm
6 SPEED CLOSE RATIO + REVERSE ALUMINIUM ALLOY CASING. HYDRAULIC CLUTCH.
Indirect multi-port grouped fuel injection, Twin fuel filters
Continuous flow 3.5 bar electric fuel pump. 13 gallon aluminum fuel tank
Bronze welded steel tube. Powder coated finish.
Aluminum bulkheads. Left hand drive
Double unequal length TIG welded fabricated wishbones front and rear
Lightweight fabricated uprights front and rear
Outboard dampers front and rear
Alloy steel coil springs front and rear
Rack and pinion cast alloy steering rack 1.7 turns lock to lock
Collapsible offset steering column. Adjustable rod ends.
305mm race suede covered steering wheel.
LCD Digital display, speedometer, tachometer, water, fuel, odo, trip
Warning lights: Ignition, lights, brake, oil, beam, indicators, alarm
Length 3215mm. Width 1850mm. Height 1425mm.
Track 1585mm front and rear. Wheelbase 2348mm.
Approach angle 71 degrees. Departure angle 82 degrees
Projector headlamps. LED indicators, stop/tail/side/repeaters.
Rear fog lamp, reverse lamp, number plate lamp. Horn. Front and rear mudguards.
0-60 mph 3.4 seconds (0-100kph)est.
0-100mph 8.7 seconds (0-165kph)est.
Top speed 125 mph est.
**Pictures may not be of exact model**
Electronic coil over plug ignition. Hondata engine management system.
Thatcham Immobilizer system
Pressurised, centrifugal 82L/min. coolant pump
Front mounted fabricated radiator
ITG foam filter system
Fabricated stainless steel exhaust manifold. Stainless silencer.
240mm ventilated discs. Tilton aluminium racing pedal box.
Twin master cylinders adjustable front/rear bias. Parking brake
7Jx18 12 spoke alloy Front and rear
Non structural roto- mould toughened polyethylene. Composite mix.
Individual seat units composite woven cloth, 5 position adjustment.
2" four point quick release full harnesses
